Medical Grade Monitor

Medical 4K Endoscope Monitor 32＂

It can be used for arthroscopy, ENT, PTED(percutaneous transforaminal endoscopic discectomy), cystoscope, percutaneous nephroscope, ventriculoscope, ductoscope, hysteroscopy, proctoscope, sigmoidoscope, urology resectoscope, plastic surgery endoscope, laparoscope, ductoscopy, breast implant endoscope, thoracoscopy, fiber nasopharyngoscope, fiber choledochoscopy, fber bronchoscope, fiber ureteroscope, TAPP hernia repair, lacrimal passage, minimally invasive varicose veins, etc.

Model: MT-YC320C/MT-YC3217/MT-YC3218

Brand: Shrek

Product Type: Medical Grade Monitor

Warranty: Five years

Leave A Message Live Chat +86-21-58189111

It adopts widescreen 4K LCD panel with accurate color rendering, excellent layering, smooth and dynamic images and expanded visual scope, which meet the current rapidly changing demands for medical displays. At the same time, it's able to provide clear and precise observation of surgical sites in minimally invasive surgery. This product is perfectly suited to meet the requirements of various kinds of endoscopic displays or operating room and ICU displays due to its white frame, waterproof design, antibacterial treatment, compliance with electromagnetic compatibility regulations and multiple video input/output interfaces.

Advantage

Accurate color rendering
ODS menu, parameters adjustable
Smooth and Dynamic Images
Compliance with operating room sterilization and anti-interference requirements
Multiple interface types, strong universality
Excellent Layering

Gallery

Medical 4K Endoscope Monitor 32＂ Gallery

Parameter

Model	MT-YC320C	MT-YC3217	MT-YC3218
Adjust the menu	Button	Button	Touchscreen
Display size	698.4(H)*392.85(V)mm	697(H)*392(V)mm	697(H)*392(V)mm
Maximum resolution	SXGA 3840x2160 UHD	SXGA 3840x2160UHD	SXGA 3840x2160UHD
Display color	1.07 billion colors	1.07 billion colors	1.07 billion colors
Contrast	1000:1	1300:1	1300:1
Brightness	350 cd/m2	1000 cd/m2	1000 cd/m2
Response time	6ms	14ms	14ms
Viewing angle	89/89/89/89(TyP)(CR≥10)	89/89/89/89(TyP)(CR≥10)	89/89/89/89(Typ)(CR≥10)
Power	100W MAX	138W MAX	138W MAX
Input voltage	100-240VAC,50-60Hz，1.4A 12V⎓8.5A,102W
Signal interface	HDMI,DM,DP,VGA,USB,RS232	HDMI,DM,DP,VGA,USB,RS232	HDMI,DM,DP,VGA,USB,RS232

Recommended Surgical Departments
