REAL optical 3D 4K technology: dual-channel 4K optical signal acquisitior
dual 1/1.8 super CMOS,with pixel fusion technology.
Model: SY-UHD3000
Brand: Shrek
Product Type: Medical Endoscope Camera
Warranty: Five years
1. Dual-lens optical path design: Utilizing independent dual optical channels (e.g., parallel or converging optical paths), the system simulates the human eye's interpupillary distance (adjustable from 55-75mm), achieving native stereoscopic imaging through physical light splitting rather than electronic synthesis.
2. Zero-delay parallax synchronization: Dual CMOS sensors capture images in strict synchronization, eliminating image misalignment associated with electronic 3D and ensuring spatial and temporal consistency between left and right eye images.
Resolution: horizontal resolution is no less than 2300 lines. Real color, clear image,strong three-dimensional sense.
Special anti-jamming processing, effectively handle the disturbing voltage produced oy eectrosuraica unit.
3D depth of field is adjustable, and the appropriate depth of field can be adiusted accordina to customer needs.
Dual HDMl2.0 output, both support 4K and 3D signa output.
With freezing and zoom function.
Support local recording of 4K 60 2D files and external recording of 4k 60 3D file.
| lmage Sensor | 1/1.8 CMOS Sony Color Super HAD CMOS |
| Video output | USB、VGA、HDMI、RS232 |
| Effective pixels | ≥3840x2160pixel |
| Scanning Frequency | N:60HZ P:60HZ |
| Scan mode | Progressive scan |
| Horizontal resolution | >2300 lines |
| Electronic shutter | AWC/MWC(1/5(60)~1/60.00s) |
| Digital Zoom | 0-60x |
| DNR | 3D Denoise |
| SNR | ≥50dB |
| Brightness | ODS adjustable |
| White balance | AWC/MWC/One step WB |
| Min illumination | F1.2≤0.1lux |
| DSS | 30x |
| Fuse | F1AL 250V AC |
